1100 Aluminum Foil
Introduction
1100 Aluminum foil is pure aluminum, the aluminum content is more than 99%. 1100 Alloy compared to 1060 and 1070 aluminum foil, the content of (Fe + Si) in 1100 aluminum foil is higher than 1060 and 1070, and the content of Fe can improve the strength and toughness of aluminum foil. 1100 aluminum foil has good formability, corrosion resistance, thermal conductivity and certain strength.
Introduction of 1100 Aluminum Foil
1100 Aluminum foil is pure aluminum, the aluminum content is more than 99%. 1100 Alloy compared to 1060 and 1070 aluminum foil, the content of (Fe + Si) in 1100 aluminum foil is higher than 1060 and 1070, and the content of Fe can improve the strength and toughness of aluminum foil. 1100 aluminum foil has good formability, corrosion resistance, thermal conductivity and certain strength. It is widely used in heat exchangers, air-conditioning foils in the refrigeration industry, storage in the chemical and food industries containers, capacitor casing materials in the electronics industry, etc.
The Product Specification of 1100 Aluminum Foil
|
Alloy |
1100 aluminum foil |
|
Temper |
F,O,H14,H16,H18,H19,H22,H24,H26,H28,etc. |
|
Thickness(mm) |
0.015-0.2 |
|
Width(mm) |
100-1600 |
|
Length (mm) |
C |
|
Surface |
Mill finish |
|
ID |
76mm,152mm,408mm,508mm or customized |
|
Standard |
ASTM-B-209M,BS EN 485-2,BS EN 573-3,GB/T3880-2008 |
|
Certificate |
Mill Test Certificate, Certificate of origin: Form A, Form E, CO |
|
Package |
Export standard, Eye to sky or eye to wall |
|
Application |
Electronic components, food packaging. |
| Chemical Composition of 1100 aluminium foil | ||||||||||
| Alloy | Si+Fe | Cu | Mn | Mg | Cr | Zn | Ti | Others | Al | |
| Individual | Total | |||||||||
| 1100 | 0.95 | 0.05-0.2 | 0.05 | - | - | 0.1 | - | 0.05 | 0.15 | 99 |
| Mechanical propertiesof 1100 aluminium foil | ||||||
| Alloy | Temper | Thickness(mm) | Tensile Strength（Mpa） | Yield Strength（Mpa） | Elongation(%) | Cupping test value I.E/mm |
| 1100 | O | 0.08-0.10 | 80-110 | ≥50 | ≥18 | ≥6.0 |
| 0.10-0.20 | 80-110 | ≥50 | ≥20 | ≥6.5 | ||
| H22 | 0.08-0.10 | 100-130 | ≥60 | ≥18 | ≥5.5 | |
| 0.10-0.20 | 100-130 | ≥60 | ≥20 | ≥6.0 | ||
| H24 | 0.08-0.10 | 115-145 | ≥70 | ≥15 | ≥5.0 | |
| 0.10-0.20 | 115-145 | ≥70 | ≥18 | ≥5.5 | ||
| H26 | 0.08-0.10 | 130-160 | ≥90 | ≥8 | ≥4.0 | |
| 0.10-0.20 | 130-160 | ≥90 | ≥10 | ≥4.5 | ||
| H18 | 0.08-0.20 | ≥160 | - | ≥1 | - | |
The Product Features of 1100 Aluminum Foil
● 1100 Aluminum foil has high plasticity, good electrical and thermal conductivity.
● 1100 Aluminum foil has high purity, clean degreasing, less holes, and good product shape.
● The surface of 1100 aluminum foil has no black oil spots, scratches, bright lines, roll marks and other defects.
The Application of 1100 Aluminum Foil
1100 Aluminum foil is widely used in food packaging, aluminum foil gaskets, electrolytic capacitors, electronic components, etc.
